Model 475pro

7.5 m working width

The ideal header for harvesting high-yielding maize. The forager header 475pro with rotary intake, consisting of four intake drums and two conveyor drums, is characterized by its simple and solid design.

Why 475pro?

EVEN MORE RANGE

With the KEMPER 400pro series rotary harvesting units, you make the decision for the smoothest possible harvest, especially when the going gets tough.
High reliability

Our rotary harvesting units are based on years of experience and extensive know-how. In use all over the world, sometimes under extreme conditions, they prove their strength day after day - as does the 475pro: reliable and always ready for action.

Versatile in use

Under extreme conditions in maize over 4.0 m and different row spacings, the 475pro shows its true capabilities - and also in other crops such as sorghum, sunflowers, whole crop silage (GPS) and many more.

Dealers near you
To the dealer overview
iconicon
technical data

Convinces ALSO in numbers

475pro

line image
Length
2.78m
Total width
7.55m
Height
1.52M
Working width
7.50M
Transport width
3.30M
Weight
3600kg
product configurator
This way
iconicon
Additional equipment

Useful options

For special operating conditions, KEMPER offers some advantageous additional equipment for the 400pro series, which makes work easier.
electro-hydraulic flotation system
The electro-hydraulic flotation system ensures precise guidance of the rotary harvesting unit along the ground contour, even on uneven terrain. The result is an even stubble pattern that impresses even in demanding conditions.
steering sensors in the center tip
The steering sensors in the center point reliably guide the forage harvester in the field and keep it on the right track. This noticeably reduces the driver's workload, increases precision and ensures smooth operation even during long operations and in difficult conditions.
height-adjustable tips
If the feed is lying on the floor over a large area, a special set with height-adjustable tips can be installed.
Attachment with tilt adjustment
A deep cut is easily possible with a KEMPER forager header if the operating conditions require it. The header angle adjustment allows the header to be set flat or at an angle, regardless of the tire size. This allows the cutting angle to be optimally adapted to stock levels or different tire sizes and ensures reliable piston retraction and a uniform cutting height.
Rigid stem lifter tips
The rigid stem lifter tips are helpful when picking up plants lying on the ground.
heavy duty packages wear parts
The wear parts are available in two different heavy-duty packages - with standard knives & with heavy-duty knives.

Both variants include high-quality components such as Hardox feed drums (1) Hardox cross conveyor drums (2) and Hardox skids (3), which ensure greater durability and resistance.

The Heavy Duty package with standard blades already offers a significantly longer service life compared to the basic equipment. The Heavy Duty package with Heavy Duty blades is available for even more extreme requirements. This variant is additionally equipped with Heavy Duty blades with coated cutting tips (4) and is ideal for intensive continuous use under the toughest conditions.
Free advice

Interested in the 475pro?

Are you interested in the 475pro or not quite sure which model is right for you? Find the right contact person in your area via our dealer directory and get non-binding advice.
